Sensor & Imaging

• Image Sensor: 2 × 1/2.7″ Image Sensor
• Processor: Ingenic-T23ZN
• Resolution: 4MP (2MP + 2MP)
• Compression Format: H.265
• Lens: 3.6mm + 8mm dual-lens
• Lens Angle: 95° + 48°
• Night Vision: Full-color or Infrared (selectable mode)
• Minimum Illumination: 0.001 Lux
• IR LED Distance: 30 m
• White LED Distance: 20 m

Functions & Detection

• Detection Type: PIR + AI Human Detection
• Detection Distance: 0 – 12 m
• Detection Angle: 110°
• Alarm: Real-time calling or push notification
• Auto Tracking: Supports dual-video linkage and humanoid tracking
• Alarm Lights: Red and Blue Flashing Lights
• Custom Arming Time: Supported

Movement & Control

• Pan Range: 270°
• Tilt Range: 90°
• Rotation Speed: 55°/s (Horizontal), 40°/s (Vertical)

Connectivity

• Network: 4G (Bands depend on region: CN / AS / EU / AU / AM / JP)
• App: UBox (Remote Viewing and Playback)

Audio

• Speaker: Built-in 3W Speaker
• Microphone: Built-in Microphone (Voice Monitoring up to 20 m)
• Two-way Voice Intercom: Supported

Storage & Power

• Local Storage: TF Card (Max 128 GB)
• Cloud Storage: Supported for alarm recording
• Power Supply: Solar Panel + Built-in Batteries (Monocrystalline Silicon)
• Solar Panel Power: 7W
• Battery Capacity: 10400 mAh
• Power Consumption: 4.5W (operating), 0.003W (standby)

Operating Conditions

• Waterproof Rating: IP66 (Indoor/Outdoor Use)
• Operating Temperature: -30°C ~ +60°C
• Humidity: 0% – 90% RH

Additional Information

• Dual 4MP lenses ensure wide-angle and telephoto coverage.
• Supports red and blue flashing lights during alarm events.
• Built-in AI detection reduces false alerts from non-human movements.
